TYP802 High side Z type desuperheater: * low noise damping plate structure
* advanced digital positioning and control technology
* the valve cage, the valve core, the nozzle can be assembled and disassembled conveniently, which is convenient for the maintenance of the
* anti cavitation, flashing, cavitation, anti corrosion, erosion resistant structure
*The two seat valve structure balance valve, adjustment range, stable operation, no blocking
* the device, vacuum system and reducing temperature system separately, mainly used in harsh conditions, such as high temperature and pressure, avoid minus direct scouring water body parts, or for superheated steam reduced to saturated steam conditions, the main consideration of the steam flow rate is low, the ring baffle plate type nozzle structure, enable desuperheating water fully atomized, achieve very good temperature reducing effect.

Model		Description
TYP802
Valve type	TYP800	Split type
	TYP801	High side angle type
	TYP802	High side Z type
	TYP803	Integral type
Actuator	A	Single spring film type cylinder
	B	Multi spring film type cylinder
	C	Piston type single acting cylinder
	C1	Double acting cylinder
	D	Electric
	G	Gas-liquid dynamic
	H	Electro hydraulic power
Steam flow	t/h	Steam circulation tonnage per hour
First grade steam pressure	P1	P1<=10Mpa
Second grade steam pressure	P2	P2≤0.98MPa时，The change range of P2 is P2±0.4MPa； 0.98＜P2≤3.82MPa时，The change range of P2 is P2±0.06MPa； P2＞3.82MPa时，The change range of P2 is P2±0.15MPa。
First grade steam temperature	t1	t1<=540℃
Second grade steam temperature	t2	t2±4℃
Pressure relief valve diameter		DN15-DN500
Temperature reducing valve diameter		DN15-DN500
Outlet device diameter		DN40-DN1000
remarks		Other description
Sample： TYP800-B-40t/h-4Mpa/1Mpa-400℃/190℃-DN25-DN20-DN50-WCB Split, multi spring film, the steam flow 40t/h, the valve before the pressure 4Mpa, the valve after the pressure 1Mpa, the valve temperature of 400, Valve temperature 190 degrees Celsius, the pressure relief valve diameter DN25, the temperature valve diameter DN20, outlet device diameter DN50, cast steel material。
